Main features:
| Input voltage | DC - 12V (+- 3V) |
| Consumption | 10W |
| Temperature | 20 C⁰ +45C⁰ |
| Radiated power | 0.250W |
| Weight | 1kg |
| Mount | V mount |
MPEG-4 H264 Encoder:
| MPEG-4 H264 SD-HD encoding | 4:2:0 – MP@ML 10MB/s |
| Input impedance analog composite video | BNC 75 Ω |
| Input impedance digital video HD SDI | BNC 75 Ohm |
| Input impedance symmetrical Audio | XLR 600 Ohm |
| Maximum level of video | 1 V p / p |
| Maximum level of audio | 0 dB, +6 dB |
| Discretization frequency of the audio signal | 32, 44.1,48 kHz |
| Bitrate of the digital audio signal | 64 to 256 Kbit |
| SNR ( signal to noise ratio) video signal | 50 Db |
| SNR ( signal to noise ratio) audio signal | 70 Db |
| Nonlinear distortion | 0.01% |
| Signal delay | 400 ms |
COFDM modulator
| Modulation type | COFDM -2K 8K QPSK QAM 16 QAM 64 |
| Frequency range | from 2200 - 2700 MHz 1150 - 1425MHz, 1000 - 1275 MHz, 800 - 1125 MHz, 775-1025 MHz, 625 - 910 MHz |
| Bandwidth | 6, 7 or 8 MHz |
| Adjustable output level with 15 steps | 50-250 mW |
| Error protection | |
| Outside code Reed Solomon | 204, 188, J = 8 |
| Shifting - Convolution interleaving | I=12, M=17 |
| Inner code - Convolution code | 171, 133 |
| Programmable coefficients | 1/2, 2/3, 3/4, 5/6, 7/8 |
| Protective intervals | 1/4, 1/8, 1/16, 1/32 |
| Output connector | N type female |
Rezcom reserve its right to change some of the parameters in order to improve the quality and the reliability of its equipment
